AVModel

Scenario

Let's have an Airport

Airport has many Airplanes
Each Airplane has many Flights (Each Flight belongs to Airplane)
Each Flight has many Passengers (Each Passenger belongs to Flight)
Each Passenger belongs to Service /first or second class/ (so Service has many Passengers)

And now let's play with all this data and Commit and save it, or Rollback at once!

Add src/com/vangelov/sqlite/AVModel.java to your project.

Create AirplaneModel.java public class AirplaneModel extends AVModel { public AirplaneModel() {} public AirplaneModel(SQLiteDatabase db) { super(db); } @Override public String getTableName() { return "AIRPLANES"; } @Override public String getPrimaryKey() { return "ID"; } @Override public void setRelations() { setHasMany("flights", FlightModel.class, "AIRPLANE_ID"); } } Create FlightModel.java public class FlightModel extends AVModel { public FlightModel() {} public FlightModel(SQLiteDatabase db) { super(db); } @Override public String getTableName() { return "FLIGHTS"; } @Override public String getPrimaryKey() { return "ID"; } @Override public void setRelations() { setBelongsTo("airplane", AirplaneModel.class, "AIRPLANE_ID"); setHasMany("passengers", PassengerModel.class, "FLIGHT_ID"); } } Create PassengerModel.java public class PassengerModel extends AVModel { public PassengerModel() {} public PassengerModel(SQLiteDatabase db) { super(db); } @Override public String getTableName() { return "PASSENGERS"; } @Override public String getPrimaryKey() { return "ID"; } @Override public void setRelations() { setBelongsTo("flight", FlightModel.class, "FLIGHT_ID"); setBelongsTo("service", ServiceModel.class, "SERVICE_ID"); } } Create ServiceModel.java public class ServiceModel extends AVModel { public ServiceModel() {} public ServiceModel(SQLiteDatabase db) { super(db); } @Override public String getTableName() { return "SERVICES"; } @Override public String getPrimaryKey() { return "ID"; } @Override public void setRelations() { } }

How to get a collection of all Airplanes:

private AirplaneModel airplaneModel;
private SQLCollection airplanes;
airplaneModel = new AirplaneModel((SQLiteDatabase)mDb);
airplanes = airplaneModel.find_all();

Get a single airplane from the airplanes collection:

private SQLRow selectedPlane = null;
selectedPlane = (SQLRow) airplanes.get(position);

Get flights of this plane:

SQLCollection flights = (SQLCollection) selectedPlane.getRelation("flights");

Add a flight:

SQLRow newFlight = (new FlightModel(mAirportDatabase.mDb)).newRow();
flights.add(newFlight);

Change Airplane data through flight model

SQLRow airplane = (SQLRow) newFlight.getRelation("airplane");
airplane.put("is_busy", 0);

Save changes to SQLite database:

airplanes.save();

Methods of AVModel:

public SQLRow newRow();
public int update(ContentValues values,String whereClause,String[] whereArgs);
public long replace(ContentValues initialValues);
public long replaceOrThrow(ContentValues initialValues);
public long insert(ContentValues values);
public long insertOrThrow(ContentValues values);
public int delete(String whereClause,String[] whereArgs);
public SQLRow find(int id);
public SQLCollection find_with_limit(String[] columns, String selection, String[] selectionArgs, String groupBy, String having, String orderBy, String limit);
public SQLCollection find_distinct(boolean distinct, String[] columns, String selection, String[] selectionArgs, String groupBy, String having, String orderBy, String limit);
public SQLCollection find_with_factory(SQLiteDatabase.CursorFactory cursorFactory,boolean distinct, String[] columns, String selection, String[] selectionArgs, String groupBy, String having, String orderBy, String limit);
public SQLCollection find_all();
public SQLCollection find_all(String[] columns, String selection, String[] selectionArgs, String groupBy, String having, String orderBy);
public SQLRow find_one(String[] columns, String selection, String[] selectionArgs, String groupBy, String having, String orderBy);

class SQLRow extends HashMap<String, Object> with additional methods:

public Object getRelation(String key,boolean reload);
public int remove();
public int save();

class SQLCollection extends ArrayList<SQLRow> with additional methods:

public void save();
public void clear(boolean includeRelatedCollections);
public boolean remove(Object object,boolean includeRelatedCollections);
