An open-source, free-tier based Progressive Web App (PWA) and Web Application designed to assist individuals with disabilities in navigating public spaces more effectively, providing wheelchair-accessible routes and audio guidance.

Live Demo

This project aims to create a practical navigation tool for people with mobility or visual impairments. It leverages free tiers of modern web services and open-source technologies to provide features like:

• Route planning with accessibility filters (e.g., wheelchair accessibility, avoiding stairs).
• Turn-by-turn audio guidance using the Web Speech API.
• Offline capabilities through PWA service workers.
• User location display.
• A clean, responsive, and accessible user interface.

The goal is to build a useful tool while demonstrating proficiency in full-stack development with specific constraints (zero budget).

• Route Planning: Enter origin and destination to calculate routes via Google Maps Directions API.
• Accessibility Parameters: Basic filtering passed to backend (e.g., avoid=stairs).
• Map Display: Interactive map rendering using @react-google-maps/api.
• Route Rendering: Displays calculated routes on the map via DirectionsRenderer.
• Text Directions: Shows step-by-step instructions.
• Audio Guidance: Reads out current/selected direction steps using Web Speech API (TTS).
• User Location: Displays the user's current location on the map (requires browser permission).
• Responsive UI: Adapts layout for desktop (side panel) and mobile (bottom sheet panel).
• PWA: Installable as a Progressive Web App with basic offline asset caching.

• Basic Authentication Flow: User sign-up, sign-in, profile management using Clerk (frontend components). Backend token verification setup.
• Authentication Integration: Fully protect relevant backend endpoints and associate data with users.
• Saved Routes: Allow authenticated users to save and reload frequently used routes.
• User Preferences: Save user settings (mobility needs, default mode, voice choice) via backend API.
• Accessibility Data:
  • Integrate custom accessibility data (ramps, hazards, etc.) from MongoDB into route planning.
  • Allow users to submit/verify accessibility points (requires moderation).
• Proactive Audio Guidance: Trigger audio instructions automatically based on user proximity to the next maneuver.
• Offline Route Caching: Save calculated route data (not just assets) for offline use.
• User Feedback Mechanism: Implement an in-app form or link for users to report issues or suggest improvements.
• Enhanced Testing: Increase unit, integration, and end-to-end test coverage. Add automated accessibility testing.
• Error Handling: Implement more robust error handling (e.g., React Error Boundaries).

• Frontend:
  • React.js (with Vite)
  • React Router DOM
  • Tailwind CSS
  • @react-google-maps/api
  • Web Speech API (Text-to-Speech)
  • vite-plugin-pwa (Workbox for Service Worker)
• Backend:
  • Flask (Python Web Framework)
  • Gunicorn (WSGI Server)
  • requests (for Google Maps API calls)
  • Flask-Cors
  • python-dotenv
  • polyline (for decoding routes)
• Database:
  • MongoDB Atlas (Free Tier M0)
  • pymongo (Python Driver)
• Maps & Navigation:
  • Google Maps Platform (Free Tier + $200 credit)
    • Maps JavaScript API
    • Directions API
    • Geocoding API (Optional/Implied)
    • Places API (Optional)
• Deployment:
  • Frontend: Vercel (Free Tier - Hobby)
  • Backend: Render (Free Tier - Web Service)
  • Database: MongoDB Atlas (Free Tier - M0 Cluster)

Follow these instructions to set up the project locally for development.

• Node.js (v18+ recommended) and npm/yarn
• Python (v3.9+ recommended) and pip
• Git
• Accounts:
  • Google Cloud Platform (for Maps API Keys - Billing must be enabled, but free tier/credit applies)
  • MongoDB Atlas (for database)
  • Vercel & Render (for potential deployment)
  • GitHub (for cloning)

IMPORTANT: Never commit files containing secrets (.env, .env.local) to Git. Ensure they are listed in your root .gitignore file.

1. Clone the repository:

   git clone https://github.com/Garbii1/accessible-navigation-app.git
   cd accessible-navigation-app

2. Backend (backend/) Setup:

   • Navigate to the backend directory: cd backend
   • Create and activate a virtual environment:

     python -m venv venv
     # Windows:
     # venv\Scripts\activate
     # macOS/Linux:
     # source venv/bin/activate

   • Install Python dependencies: pip install -r requirements.txt
   • Create a .env file in the backend/ directory with the following variables (replace placeholders with your actual keys/URIs):

     MONGO_URI=YOUR_MONGODB_ATLAS_CONNECTION_STRING
     GOOGLE_MAPS_API_KEY=YOUR_BACKEND_GOOGLE_MAPS_API_KEY_HERE # Restricted by IP
     FRONTEND_URL=http://localhost:5173 # Or your frontend dev port
     # Optional: FLASK_DEBUG=True # For local development only

     • Get MONGO_URI from MongoDB Atlas (Database -> Connect -> Connect your application -> Python).
     • Get GOOGLE_MAPS_API_KEY (Backend Key) from Google Cloud Console (restricted by IP Address).

3. Frontend (frontend/) Setup:

   • Navigate to the frontend directory: cd ../frontend (from backend) or cd frontend (from root)
   • Install Node dependencies: npm install (or yarn install)
   • Create a .env.local file in the frontend/ directory (this file is ignored by Git and overrides .env):

     # Local development environment variables

     # URL for the LOCAL backend API (ensure port matches backend setup)
     VITE_API_BASE_URL=http://localhost:5001

     # Your Google Maps JavaScript API Key (Frontend Key)
     # Ensure localhost:PORT is added to HTTP referrers in Google Cloud Console
     VITE_GOOGLE_MAPS_API_KEY=YOUR_FRONTEND_GOOGLE_MAPS_API_KEY_HERE

     • Get VITE_GOOGLE_MAPS_API_KEY (Frontend Key) from Google Cloud Console (restricted by HTTP Referrers).

1. Start Backend Server:
   • Open a terminal in the backend/ directory.
   • Activate the virtual environment (source venv/bin/activate or venv\Scripts\activate).
   • Run the Flask development server: python app.py (It should run on the port specified in VITE_API_BASE_URL, e.g., 5001).
2. Start Frontend Dev Server:
   • Open another terminal in the frontend/ directory.
   • Run the Vite dev server: npm run dev (Usually runs on port 5173).
   • Open your browser to http://localhost:5173.

(Assuming Blueprint structure)

• Navigation (/api/route)
  • POST /: Calculates route based on origin, destination, preferences.
• User Data (/api)
  • POST /routes: Saves a route for the logged-in user. (@require_auth)
  • GET /routes: Gets a list of saved routes for the logged-in user. (@require_auth)
  • GET /routes/<route_id>: Gets details of a specific saved route. (@require_auth)
  • DELETE /routes/<route_id>: Deletes a saved route. (@require_auth)
  • GET /user/preferences: Gets preferences for the logged-in user. (@require_auth)
  • PUT /user/preferences: Updates preferences for the logged-in user. (@require_auth)
• Accessibility Data (/api/accessibility-points)
  • POST /: Adds a new accessibility point report. (@require_auth)
  • GET /: Gets accessibility points near a given lat/lng (Public).
  • GET /<point_id>: Gets details of a specific accessibility point (Public).

• Frontend (Vercel):
  • Connect your GitHub repository to Vercel.
  • Configure the Root Directory to frontend.
  • Set the Framework Preset to Vite.
  • Add the necessary Environment Variables (VITE_API_BASE_URL, VITE_GOOGLE_MAPS_API_KEY) for the Production environment in the Vercel project settings.
• Backend (Render):
  • Connect your GitHub repository to Render as a "Web Service".
  • Ensure requirements.txt and Procfile are present in the backend/ directory.
  • Render should detect Python and use pip install -r requirements.txt for build and gunicorn app:app --log-file=- for start command (from Procfile).
  • Add the necessary Environment Variables (MONGO_URI, GOOGLE_MAPS_API_KEY, FRONTEND_URL) in the Render service settings.
  • Ensure Render's outbound IP addresses are allowed in MongoDB Atlas Network Access rules.
• Database (MongoDB Atlas):
  • Use the free M0 shared cluster.
  • Configure Network Access to allow connections from Render and your local IP for testing.

• Google Maps API Keys: Ensuring correct restrictions (HTTP Referrers for Frontend Key, IP Addresses for Backend Key) and enabling the necessary APIs (Maps JavaScript, Directions) for each key was crucial. The RefererNotAllowedMapError specifically required adding Vercel preview deployment URLs to the allowed referrers.
• CORS: Configuring the Flask backend (Flask-Cors) to allow requests from the specific frontend origin (localhost for dev, Vercel URL for prod) using the FRONTEND_URL environment variable was necessary. Also ensuring the frontend correctly requested paths starting with /api/.
• Service Worker Caching: Encountered issues with the PWA service worker caching empty files. Resolved by ensuring the build process completed without errors. Also fixed a runtime error in the service worker by correctly embedding the VITE_API_BASE_URL string during build time using loadEnv in vite.config.js, rather than trying to access import.meta.env at runtime within the worker. Aggressive browser cache/service worker clearing was needed during debugging.
• Private npm Packages (If Applicable): Required setting up NPM_TOKEN environment variable in Vercel/Render and configuring .npmrc in the project to authenticate with the private registry during build.

• Muhammed Babatunde Garuba
• GitHub: @Garbii1

This project is licensed under the MIT License.
